Inconel 625 Stainless steel capillary Tubing

Material Grade : 304 ，316L, 310S, 2205, 304, 825, 625, etc

Wall thickness: 0.8MM-1.65MM

Outer diameter of steel pipe: 1/8 "-2"

Length: 50M-10000M

Working pressure: 50MPA-120MPA

Note: Material specifications can be customized according to user requirements

PRODUCT DESCRIPTION

Product Description

We Supply Inconel 625 Stainless steel capillary tube, The manufacture of Stainless steel Super Monel 625 Capillary tubing , which is designed to handle highly corrosive conditions and situations were high strength is required. High molybdenum, chromium and nitrogen content in Inconel 625 help the material withstand pitting and crevice corrosion. The material is also resistant to chloride stress corrosion cracking, to erosion corrosion, to corrosion fatigue, to general corrosion in acids. This alloy has good weldability and very high mechanical strength.Alloy 625 seamless capillary tubing /coil tubes are our Star products.

Standard Stainless Steel Capillary Tubing Pressure Rating and Length:

Stainless Steel Capillary Tubing
ITEM	Grade	Size (MM)	Length (Mtrs)	Pressure (Mpa)
1	316L 304L 304 625 825 2205 2507	1/8″×0.025″	3200	80
2	316L 304L 304 625 825 2205 2507	1/8″×0.035″	3200	100
3	316L 304L 304 625 825 2205 2507	1/4″×0.035″	2000	100
4	316L 304L 304 625 825 2205 2507	1/4″×0.049″	2000	100
5	316L 304L 304 625 825 2205 2507	3/8″×0.035″	1500	80
6	316L 304L 304 625 825 2205 2507	3/8″×0.049″	1500	100
7	316L 304L 304 625 825 2205 2507	1/2″×0.049″	1000	80
8	316L 304L 304 625 825 2205 2507	1/2″×0.065″	1000	100
9	316L 304L 304 625 825 2205 2507	φ3mm×0.7mm	3200	80
10	316L 304L 304 625 825 2205 2507	φ3mm×0.9mm	3200	100
11	316L 304L 304 625 825 2205 2507	φ4mm×0.9mm	3000	100
12	316L 304L 304 625 825 2205 2507	φ4mm×1.1mm	3000	100
13	316L 304L 304 625 825 2205 2507	φ6mm×0.9mm	2000	100
14	316L 304L 304 625 825 2205 2507	φ6mm×1.1mm	2000	100
15	316L 304L 304 625 825 2205 2507	φ8mm×1mm	1800	80
16	316L 304L 304 625 825 2205 2507	φ8mm×1.2mm	1800	100
17	316L 304L 304 625 825 2205 2507	φ10mm×1mm	1500	70
18	316L 304L 304 625 825 2205 2507	φ10mm×1.2mm	1500	70
19	316L 304L 304 625 825 2205 2507	φ10mm×2mm	500	100
20	316L 304L 304 625 825 2205 2507	φ12mm×1.5mm	500	80

STAINLESS STEEL CAPILLARY TUBE SPECIFICATION

Size Range	1/8” to 5/8” OD in thickness ranging from 0.1mm to 2.0mm.
Thickness	0.1mm to 2.0mm, SCH 5/5S, 10/10S, 20/20S, 40/40S, 80/80S, 120/120S, 160/160S as per ANSI B36.19/36.10
Wall Thickness	0.08 – 2 .0mm
Outside Diameter	0.3 –12.0 mm
Specification	ASME / ASTM A213, ASTM A688 / A688M - 08, ASTM A803 / A803M, ASTM A556 / A556M, ASME SA556, ASME SA688,
Material	SS 304, ,SS 316L,Alloy 625/825 2205/2507
Finish	Pickled, Polished, Bright Annealed, Electrolytic Polished
Form	Round, Strait, Hydraulic etc.
Type	As Welded, EFW, ERW, Seamless, Semi Seamless, Bead Removed
Mill Test Certificate	EN10204 3.1
Packing	Sleeved, Ends Capped, Wooden Boxed

We offer Inconel 625 Seamless Capillary tubing in small bore sizes and precise thickness are available as per the requirements of clients. Inconel 625 Capillary Tubes sizes range from 0.30 mm to 8.00 mm. They can be availed in standard or heavy wall. 625 Capillary Tube diameters of refrigerant capillary tubes range from 0.30 mm to 31.75 mm O.D. And 0.06 mm to 1.65 mm thickness and the length ranges from 1.0 mm to 6.0 mm. It is widely used in instrumentation Industries. Stainless Steel 304 capillary tubes and Stainless Steel 316L capillary tubes are available in precise cut to lengths are also highly effective in a wide range of temperatures. Long length 625 capillary tubing and Inconel 625 Seamless Capillary Pipeline are widely used for high-pressure applications.

Our offered 625 continuous Oiled pipes , 625 Capillary tubing and 625 Capillary Tubing are mostly used for Liquid/ Gas Transportation Lines, Hydraulic control lines, Medical devices and equipment’s, Chromatography applications, Measurement devices, Remote thermometer systems Small precision stainless steel antenna, Watches, Car antenna tube, Laser engraving equipment, etc.

As the largest stockholder of SS Capillary Tube includes grades 625 Capillary Tubing, SS 304L Capillary Pipeline, Stainless Steel 316L Capillary Tubing, Alloy 825 Capillary Tubing and Duplex 2205 Capillary tube, those are used in various industrial applications.

ALLOY 625 Stainless Steel Capillary Tubing China Suppliers

Chemical Composition

The chemical composition of Alloy 625 Capillary Tube is outlined in the following

CHEMICAL COMPOSITION ‐ %
C ≤0.10
Mn≤0.50
P≤0.015
S ≤0.015
Si ≤0.5
Cr 20.0‐23.0
Ni≥58.0

Mo 8.0‐10.0

Fe ≤5.0
Al ≤0.4
Ti ≤0.40
Co ≤1.0

Physical Properties

The physical properties of stainless steel grade 625 Capillary Tubes are tabulated below.

PHYSICAL PROPERTIES
Yield strength: ≥40,000 psi
Tensile strength: ≥100,000 psi

Alloy 625 Capillary Tube DIMENSIONAL TOLERANCES

SIZE OD		NOMINAL WALL THICKNESS		OUTSIDE DIAMETER TOLERANCE		LENGTH TOLERANCE		WALL THICKNESS TOLERANCE
(in)	(mm)	(in)	(mm)	(in)	(mm)	(in)	(mm)	(%)
½	12.7	0.065	1.65	+/-0.005	+/-0.13	+⅛, -0	+3.18, -0	+/-10.0%
¾	19.1	0.065	1.65	+/-0.005	+/-0.13	+⅛, -0	+3.18, -0	+/-10.0%
1	25.4	0.065	1.65	+/-0.005	+/-0.13	+⅛, -0	+3.18, -0	+/-10.0%
1½	38.1	0.065	1.65	+/-0.008	+/-0.20	+⅛, -0	+3.18, -0	+/-10.0%
2	50.8	0.065	1.65	+/-0.008	+/-0.20	+⅛, -0	+3.18, -0	+/-10.0%
2½	63.5	0.065	1.65	+/-0.010	+/-0.25	+⅛, -0	+3.18, -0	+/-10.0%
3	76.2	0.065	1.65	+/-0.010	+/-0.25	+⅛, -0	+3.18, -0	+/-10.0%
4	101.6	0.083	2.11	+/-0.015	+/-0.38	+⅛, -0	+3.18, -0	+/-10.0%
6	152.4	0.109	2.77	+/-0.030	+/-0.76	+1, -0	+25.4, -0	+/-10.0%

These 625 Capillary Tubes are sold to a wide range of industries/markets, due to their overall corrosion resistance and good machinability:

· Stainless Steel Capillary Capillary Tubing for Chemical and petrochemical

· SS Capillary Tube used for Power generation

· Stainless Steel Capillary Tubing for Renewable energy

· SS Capillary Tubing for Pulp and Paper

· SS Capillary Tube for Process piping

· Stainless Steel Capillary Capillary tubing applications for Food and beverage

· SS Capillary Tube used for Oil and gas

· Stainless Steel Capillary Tubing applications in Mining

· SS Capillary Tube used for Water/waste

· Stainless Steel Capillary Tubing application for Marine Industry
